939724 NEMA6
Wireless Bi-directional control (Two Way)
939704 NEMA6
Wireless Uni-directional control (One Way)
Features: 4 I/O Discrete
and 2 Analog 4-20mA
|
Brand/Series |
: |
939704
Series
|
|
Current, Rating |
: |
0 to 20 mA
|
|
Performance |
: |
1 Watt, Range 3
Miles LOS |
|
Frequency |
: |
900 MHz ISM Band
|
|
Antenna |
: |
External
50 ohm, optional antenna |
|
Housing Type |
: |
Polycarbonate with
(2) 1⁄2 In. NPT Wiring Access
|
|
IOs |
: |
Input: (4)
Selectable Discrete, (2) 0-20 mA Analog
Output: (4) Sourcing Discrete, (2) 0-20 mA
Analog
|
|
Power |
: |
10 to 30 VDC
|
|
Range |
: |
Up to 4.8
kilometers (3 miles)
With 939037 Yagi Antenna |
|
Standards |
: |
IEC IP67, NEMA 6
|
|
Temperature, Operating |
: |
–40° to 85°C
|
|
Configuration |
: |
DIP switch |
|
Voltage, Supply |
: |
10 to 30 VDC |
■
